AMPMODU MOD I Series

Part	Number of Rows	Shrouding	Insulation Material	Pitch - Mating	Contact Length - Post	Contact Shape	Contact Finish - Post	Contact Length - Mating	Current Rating	Termination	Number of Positions Loaded	Contact Type	Insulation Height	Connector Type	Insulation Color	Fastening Type	Style	Operating Temperature (Max)	Operating Temperature (Min)	Number of Positions	Contact Material	Material Flammability Rating	Mounting Type	Contact Finish - Mating	Contact Finish Thickness - Mating	Contact Finish Thickness - Post
TE Connectivity AMP Connectors 87655-3	1	Unshrouded	Thermoplastic	0.156 in	0.15 in	Rectangular	Tin-Lead	0.345 in	5 A	Solder	All	Male Pin	0.25 in	Header	Black	Push-Pull	Board Board or Cable	105 °C	-65 °C	3	Brass	UL94 V-0	Right Angle Through Hole	Tin-Lead	50 µin	50 µin
TE Connectivity AMP Connectors 2-87655-4	1	Unshrouded	Thermoplastic	0.156 in	0.15 in	Rectangular	Tin-Lead	0.345 in	5 A	Solder	All	Male Pin	0.25 in	Header	Black	Push-Pull	Board Board or Cable	105 °C	-65 °C	24 pos	Brass	UL94 V-0	Right Angle Through Hole	Tin-Lead	50 µin	50 µin

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

3D models and CAD resources for this part

Technical documentation and resources
