RING TONGUE TERMINAL, M4, #8, 8 AWG, 8 MM², TERMINYL SERIES, RED
53041
ActiveTE Connectivity AMP Connectors
RING TONGUE TERMINAL, M4, #8, 8 AWG, 8 MM², TERMINYL SERIES, RED
Description
General part information
53041
The 53041 is a Ring Tongue Terminal made of copper with tin plated finish. This straight closed barrel terminal features a red nylon insulator, crimp termination and accepts 8AWG wire.
Technical Specifications
Parameters and characteristics for this part
| Specification | 53041 |
|---|---|
| Color | Red |
| Contact Finish | Tin |
| Contact Material | Copper |
| Features | Serrated Termination |
| Insulation | Insulated |
| Length - Overall | 1.425 in |
| Mounting Type | Free Hanging (In-Line) |
| Stud/Tab Size | 8 Stud |
| Terminal Type | Circular |
| Termination | Crimp |
| Thickness | 0.04 in |
| Width - Outer Edges | 0.478 in |
| Wire Gauge | 8 AWG |
