640250-8
ActiveCONNECTOR HOUSING, SL-156, SOCKET, 8 POSITIONS, 3.96 MM, SL-156 SERIES CONTACTS
640250-8
ActiveCONNECTOR HOUSING, SL-156, SOCKET, 8 POSITIONS, 3.96 MM, SL-156 SERIES CONTACTS
Description
General part information
640250 Series
The 640250-8 is a 8-way 1-row Crimp Receptacle Housing made of natural color nylon GF housing. The wire-to-board connector comes with inline socket and locking ramp. The housing can be used with SL .156 contacts. Unit accepts 1.14mm square or round post, accepts keying plug 640254-1and 640255-1.
Technical Specifications
Parameters and characteristics for this part
| Specification | 640250-8 |
|---|---|
| Color | Natural |
| Connector Type | Receptacle |
| Contact Termination | Crimp |
| Contact Type | Female Socket |
| Fastening Type | Locking Ramp |
| Insulation Material | Nylon, Polyamide (PA) |
| Mounting Type | Free Hanging (In-Line) |
| Note | Contacts Not Included |
| Number of Positions | 8 |
| Number of Rows | 1 |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -55 °C |
| Pitch | 0.156 in |
