Specification	EP7L4M10C

Backshell Material, Plating	Thermoplastic
Cable Opening (Max)	0.7 in
Cable Opening (Min)	0.6 in
Color	Black
Connector Type	Male Pins, Plug
Contact Finish - Mating	Gold
Contact Material	Copper Alloy
Current Rating	0 A
Current Rating	Varies by Wire Gauge
Fastening Type	Push-Pull
Features	Backshell
Ingress Protection Description	Dust Tight, Water Resistant, Waterproof
Ingress Protection IP Rating	IP69K, IP68, IP67, IP66
Insert Material	Thermoplastic
Mounting Type	Free Hanging (In-Line)
Number of Positions	4
Operating Temperature (Max)	135 °C
Operating Temperature (Min)	-40 °C
Orientation	Keyed
Primary Material	Plastic
Shell Material	Thermoplastic
Shell Size - Insert	B
Shielding	Unshielded
Termination	Screw
Voltage Rating	600 V
Voltage Rating (Type)	DC
