592D227X9010R2T20H
ActiveVishay Dale
CAP TANT 220UF 10% 10V 2824
592D227X9010R2T20H
ActiveVishay Dale
CAP TANT 220UF 10% 10V 2824
Description
General part information
592D227X9010R2T20H
220 µF Conformal Coated Tantalum Capacitors 10 V 2824 (7260 Metric) 100mOhm
Technical Specifications
Parameters and characteristics for this part
| Specification | 592D227X9010R2T20H |
|---|---|
| Capacitance | 220 µF |
| ESR (Equivalent Series Resistance) | 100 mOhm |
| Features | General Purpose |
| Height - Seated (Max) | 0.079 in |
| Manufacturer Size Code | R |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | 2824 (7260 Metric) |
| Size / Dimension Length | 0.283 in |
| Size / Dimension Width | 0.236 in |
| Tolerance | 10 % |
| Type | Conformal Coated |
| Voltage - Rated | 10 V |
