Specification	B40921A7397M000

Applications	Automotive
Capacitance	390 µF
ESR (Equivalent Series Resistance)	20 mOhm
Height - Seated (Max)	0.413 in
Lifetime	4000 Hrs
Mounting Type	Surface Mount
Operating Temperature (Max)	125 °C
Operating Temperature (Min)	-40 °C
Package / Case	Radial, Can - SMD
Ratings	AEC-Q200
Ripple Current	2.8 A
Size / Dimension Diameter	0.394 in
Surface Mount Land Length	0.406 in
Surface Mount Land Width	0.406 in
Tolerance	20 %
Type	Hybrid
Voltage - Rated	35 V
