031-6508
ActiveMcGill Microwave Systems
RF / COAXIAL CONNECTOR, TNC RP COAXIAL, STRAIGHT BULKHEAD JACK, CRIMP, 50 OHM, LMR-200
031-6508
ActiveMcGill Microwave Systems
RF / COAXIAL CONNECTOR, TNC RP COAXIAL, STRAIGHT BULKHEAD JACK, CRIMP, 50 OHM, LMR-200
Description
General part information
031-6508
RF / COAXIAL CONNECTOR, TNC RP COAXIAL, STRAIGHT BULKHEAD JACK, CRIMP, 50 OHM, LMR-200
Technical Specifications
Parameters and characteristics for this part
| Specification | 031-6508 |
|---|---|
| Cable Group | LMR-200, Belden 7807A |
| Center Contact Material | Beryllium Copper |
| Connector Style | RP-TNC |
| Connector Type | Jack, Male Pin |
| Contact Termination | Solder |
| Fastening Type | Threaded |
| Frequency - Max | 6000 MHz |
| Housing Color | Silver |
| Impedance | 50 Ohm |
| Ingress Protection Description | Waterproof, Dust Tight |
| Ingress Protection IP Rating | IP67 |
| Mounting Feature | Bulkhead, Front Side Nut |
| Mounting Type | Panel Mount |
| Number of Ports | 1 |
| Shield Termination | Crimp |
