Specification	RJF22B05100BTX

Cable Type	Round Cable
Color	Gray
Connector Type	Ethernet, RJ45, Jack to Plug
Features	Circular Bayonet Coupling, Molded Plugs
Length	1.64 ft
Mounting Type	Panel Mount, Flange
Number of Contacts	8
Number of Positions	8
Shielding	Shielded
Style	Cat5e, Industrial Environments - IP68

RJF Series

Part	Mounting Type	Features	Cable Type	Style	Connector Type	Number of Positions	Number of Contacts	Shielding	Color	Length	For Use With/Related Products	Accessory Type	Convert From (Adapter End)	Convert To (Adapter End)	Ingress Protection Description	Ingress Protection IP Rating	Type	Shell Material	Finish	Operating Temperature (Min)	Operating Temperature (Max)	Ratings	Shell Material, Finish	Mounting Feature
McGill Microwave Systems RJFSFTP5E1219	Free Hanging (In-Line)	Molded Plugs	Round Cable	Cat5e	Ethernet Plug to Plug RJ45	8	8	Double Shielded	Black	39.99 ft
McGill Microwave Systems RJF22B15100BTX	Flange Panel Mount	Circular Bayonet Coupling Molded Plugs	Round Cable	Cat5e Industrial Environments - IP68	Ethernet Jack to Plug RJ45	8	8	Shielded	Gray	4.92 ft
McGill Microwave Systems RJFC2N		Lanyard									RJF Series Receptacle	Cap (Cover)
McGill Microwave Systems RJF2PEMWF1B	Panel Mount Square Flange	Circular Bayonet Coupling						Unshielded					6p6c (RJ11) Jack	6p6c (RJ11) Jack	Dust Tight Waterproof	IP67	Coupler	Metal	Olive Drab Cadmium Plated
McGill Microwave Systems RJF71RAG	Bulkhead Panel Mount Right Angle	Circular Bayonet Coupling						Shielded					8p8c (RJ45) Jack	8p8c (RJ45) Jack			Coupler			-40 °C	85 °C	Cat5e	Olive Drab Cadmium Plating	Front Side Nut
McGill Microwave Systems RJFTV7SA2N10100BTX	Free Hanging (In-Line)	Circular Bayonet Coupling Molded Plugs	Round Cable	Cat5e Industrial Environments - IP68	Ethernet Jack to Plug RJ45	8	8	Shielded	Gray	3.28 ft
McGill Microwave Systems RJFC6N		Lanyard									RJF Series Plug	Cap (Cover)
McGill Microwave Systems RJF7SA1B	Bulkhead Panel Mount	Circular Bayonet Coupling						Unshielded					8p8c (RJ45) Jack	8p8c (RJ45) Jack	Dust Tight Waterproof	IP67	Coupler			-40 °C	85 °C	Cat5e	Metal	Front Side Nut
McGill Microwave Systems RJF22N05100BTX	Flange Panel Mount	Circular Bayonet Coupling Molded Plugs	Round Cable	Cat5e Industrial Environments - IP68	Ethernet Jack to Plug RJ45	8	8	Shielded	Gray	1.64 ft
McGill Microwave Systems RJF2PEWF1G	Panel Mount Square Flange	Circular Threaded Coupling						Unshielded					8p8c (RJ45) Jack	8p8c (RJ45) Jack	Dust Tight Waterproof	IP68	Coupler					Cat5e		Front Side Nut

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

RJF22B05100BTX | Datasheet
