General part information
Fixed Terminal Blocks MKKDSN 1,5/3-5,08 BK
Technical documentation and resources
Parameters and characteristics for this part
| Specification | 1800103 |
|---|---|
| Color | Black |
| Contact Material - Plating | Copper Alloy - Tin Plated |
| Current | 10 A |
| Features | Interlocking (Side) |
| Housing Material | Polyamide (PA), Nylon |
| Mating Orientation | Horizontal with Board |
| Mounting Type | Through Hole |
| Number of Levels | 2 |
| Operating Temperature [Max] | 100 °C |
| Operating Temperature [Min] | -40 °C |
| Pitch [x] | 0.2 in |
| Pitch [x] | 5.08 mm |
| Positions Per Level | 3 |
| Torque - Screw [Max] | 0.6 Nm |
| Torque - Screw [Max] | 5.3 Lb-In |
| Torque - Screw [Min] | 4.4 Lb-In |
| Torque - Screw [Min] | 0.5 Nm |
| Voltage | 300 V |
| Wire Gauge [Max] | 30 AWG |
| Wire Gauge [Min] | 14 AWG |
| Wire Termination | Screw, Tension Sleeve, Clamping Yoke |
Fixed Terminal Blocks MKKDSN 1,5/3-5,08 BK
| Part | Torque - Screw [Max] | Torque - Screw [Max] | Torque - Screw [Min] | Torque - Screw [Min] | Features | Contact Material - Plating | Current | Wire Gauge [Min] | Wire Gauge [Max] | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Type | Wire Termination | Color | Mating Orientation | Number of Levels | Voltage | Positions Per Level | Pitch [x] | Pitch [x] | Housing Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Phoenix Contact 1800103 | 0.6 Nm | 5.3 Lb-In | 4.4 Lb-In | 0.5 Nm | Interlocking (Side) | Copper Alloy - Tin Plated | 10 A | 14 AWG | 30 AWG | 100 °C | -40 °C | Through Hole | Clamping Yoke, Screw, Tension Sleeve | Black | Horizontal with Board | 2 | 300 V | 3 | 0.2 in | 5.08 mm | Polyamide (PA), Nylon |
