Description
General part information
XMLP010BD71F
ELECTRONIC PRESSURE SENSORS, PRE
Technical Specifications
Parameters and characteristics for this part
| Specification | XMLP010BD71F |
|---|---|
| Accuracy | 0.5 % RH |
| Applications | Industrial Automation |
| Maximum Pressure | 435.11 PSI |
| Operating Pressure | 145.04 PSI |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -30 °C |
| Output Type | Analog Voltage |
| Output Voltage (Max) | 10 V |
| Output Voltage (Min) | 0 V |
| Package / Case | Threaded, Cylinder |
| Port Diameter | 0.25 " |
| Port Feature | GA |
| Port Gender | Male |
| Port Style | Threaded |
| Termination Style | Connector |
| Voltage - Supply (Maximum) | 33 V |
| Voltage - Supply (Minimum) | 12 VDC |
