Specification	B32924A4684M000

Applications	RFI Suppression, EMI
Capacitance	0.68 µF
Dielectric Material	Polypropylene (PP)
Features	85C/85% Humidity, 85% Humidity, 85C Humidity
Height - Seated (Max)	0.827 in
Lead Spacing	1.083 in
Mounting Type	Through Hole
Operating Temperature (Max)	110 °C
Operating Temperature (Min)	-40 °C
Package / Case	Radial
Ratings	X2
Size / Dimension Length	1.24 in
Size / Dimension Width	0.433 in
Termination	PC Pins
Tolerance	20 %
Voltage Rating - AC	350 VAC
Voltage Rating - DC	650 V
