Description
General part information
RL1210FR-070R03L
RES THICK FILM 1210 0.03 OHM 1% 0.5W(1/2W) ±1000PPM/°C PAD SMD T/R
Technical Specifications
Parameters and characteristics for this part
| Specification | RL1210FR-070R03L |
|---|---|
| Composition | Thick Film |
| Features | Current Sense |
| Height - Seated (Max) | 0.026 in |
| Number of Terminations | 2 |
| Operating Temperature (Max) | 155 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | 1210 (3225 Metric) |
| Package Name | 1210 |
| Power (Watts) | 500 mW |
| Power (Watts) Options | 1/2W |
| Resistance | 0.03 Ohms |
| Size / Dimension Length | 0.122 in |
| Size / Dimension Width | 0.102 in |
| Temperature Coefficient | 1000 ppm/°C |
| Temperature Coefficient (Highest) | 1000 ppm/°C |
| Temperature Coefficient (Lowest) | -1000 ppm/°C |
| Tolerance | 1 % |
