72702CS
ActiveCentury Spring Corp
COMP O=1.225,L= 3.50,W= .135
72702CS
ActiveCentury Spring Corp
COMP O=1.225,L= 3.50,W= .135
Description
General part information
72702CS
COMP O=1.225,L= 3.50,W= .135
Technical Specifications
Parameters and characteristics for this part
| Specification | 72702CS |
|---|---|
| Diameter - Inside | 0.955 in |
| Diameter - Outside | 1.225 in |
| End Style | Ground, Closed |
| Finish | None |
| Free Length | 3.5 in |
| Material | Music Wire |
| Rate (lbs/in) | 44 lbs/in |
| Type | Compression |
| Wire Diameter | 0.135 in |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
