L201316Q-520MHF
ActiveITG Electronics, Inc.
52.0UH, 20%, 3.50MOHM, 35.50A MA
L201316Q-520MHF
ActiveITG Electronics, Inc.
52.0UH, 20%, 3.50MOHM, 35.50A MA
Description
General part information
L201316Q-520MHF
52 µH Drum Core, Wirewound Inductor 34 A 3.5mOhm 2-DIP
Technical Specifications
Parameters and characteristics for this part
| Specification | L201316Q-520MHF |
|---|---|
| Current - Saturation (Isat) | 23.5 A |
| Current Rating | 34 A |
| DC Resistance (DCR) | 3.5 mOhm |
| Height - Seated (Max) | 1.244 in |
| Inductance | 52 µH |
| Inductance Frequency - Test | 10 kHz |
| Material - Core | Alloy Powder |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 150 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | 2-DIP |
| Package Name | 2-DIP |
| Ratings | AEC-Q200 |
| Size / Dimension Length | 1.299 in |
| Size / Dimension Width | 1.259 in |
| Tolerance | 20 % |
| Type | Drum Core, Wirewound |
