TERM BLOCK PLUG 22POS 5.08MM
1809019
ActivePhoenix Contact
TERM BLOCK PLUG 22POS 5.08MM
Description
General part information
1809019
22 Position Terminal Block Plug Housing for Female Sockets 0.200" (5.08mm) 180° Free Hanging (In-Line)
Technical Specifications
Parameters and characteristics for this part
| Specification | 1809019 |
|---|---|
| Color | Green |
| Current - IEC | 12 A |
| Current - UL | 10 A |
| Features | Retention Latches (Non-Wire Side) |
| Housing Material | Nylon, Polyamide, PA |
| Insulation Height | 0.394 in |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Free Hanging (In-Line) |
| Number of Levels | 1 |
| Number of Positions | 22 |
| Pitch | 5.08 mm |
| Plug Wire Entry Angle | 180 ° |
| Positions Per Level | 22 |
| Type | Plug Housing for Female Sockets |
| Voltage - IEC | 630 V |
| Voltage - UL | 300 V |
| Wire Gauge or Range - AWG (Max) | 20 AWG |
| Wire Gauge or Range - AWG (Min) | 14 AWG |
| Wire Gauge or Range - mm² (Maximum) | 2.5 mm² |
| Wire Gauge or Range - mm² (Minimum) | 0.2 mm² |
