Specification	XC22M4-27.000-F12NJHPK

ESR (Equivalent Series Resistance)	80 Ohm, 60 Ohm
Frequency	27 MHz
Frequency Stability	30 ppm, 10 ppm
Frequency Tolerance	10 ppm, 30 ppm
Height - Seated (Max)	0.022 in
Load Capacitance	12 pF
Mounting Type	Surface Mount
Operating Mode	Fundamental
Operating Temperature (Max)	70 °C
Operating Temperature (Min)	-20 °C
Package / Case	4-SMD, No Lead
Size / Dimension Length	0.098 in
Size / Dimension Width	0.079 in
Type	MHz Crystal
