Description
General part information
1423971
Circular Connector Distributor H-Shaped 4 (3 + PE)/4 (3 + PE) Female Sockets/Female Sockets Free Hanging (In-Line)
Technical Specifications
Parameters and characteristics for this part
| Specification | 1423971 |
|---|---|
| Connector Style | Distributor H-Shaped |
| Convert From (Adapter End) | Female Sockets |
| Convert To (Adapter End) | Female Sockets |
| Current Rating | 20 A |
| Fastening Type | Threaded |
| Housing Color | Black |
| Ingress Protection Description | Dust Tight, Water Resistant, Waterproof |
| Ingress Protection IP Rating | IP69K, IP68, IP66 |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Free Hanging (In-Line) |
| Number of Positions (Convert From) - PE | 1 |
| Number of Positions (Convert From) - Signal | 3 |
| Number of Positions (Convert From) - Total | 4 |
| Number of Positions (Convert To) | 4 |
| Number of Positions (Convert To) Breakdown | PE |
| Operating Temperature (Max) | 100 °C |
| Operating Temperature (Min) | -40 °C |
| Orientation (Convert From) | Keyed |
| Orientation (Convert To) | Keyed |
| Primary Material | Plastic |
| Shielding | Unshielded |
| Voltage Rating | 690 V |
