Specification	4646-0.75-5

Adhesive	Pressure Sensitive Adhesive (PSA)
Backing	Acrylic Foam
Carrier	Acrylic Foam
Color	Gray
Length (ft)	15 ft
Length (yd)	5 yd
Shelf Life	24 Months
Shelf Life Start	Date of Shipment
Storage/Refrigeration Temperature (Maximum)	100 °F
Storage/Refrigeration Temperature (Minimum)	40 °F
Tape Type	Double Sided, Double Coated
Temperature Range (Single)	300 °F
Thickness	0.025 in
Thickness - Adhesive	0.02 in
Thickness - Backing, Carrier	0.005 in
Usage	General Purpose
Width	0.75 in

4646 Series

...

Part	Shelf Life	Shelf Life Start	Storage/Refrigeration Temperature (Minimum)	Storage/Refrigeration Temperature (Maximum)	Backing	Carrier	Tape Type	Width	Thickness	Usage	Adhesive	Color	Temperature Range (Single)	Thickness - Adhesive	Temperature Range (Max)	Length	Thickness - Backing, Carrier	Length (yd)	Length (ft)
3M (TC) 4646CIR-1(5)	24 Months	Date of Shipment	40 °F	100 °F	Acrylic Foam	Acrylic Foam	Double Coated Double Sided	1 in	0.025 in	General Purpose	Pressure Sensitive Adhesive (PSA)	Gray	300 °F
3M (TC) 4646SQ-3(25)	24 Months	Date of Shipment	40 °F	100 °F	Polyethylene Film	Polyethylene Film	Double Coated Double Sided	3 in	0.025 in		Acrylic	Gray		0.02 in	300 °F	3 "	0.005 in
3M (TC) 4646-0.75-3(5)	24 Months	Date of Shipment	40 °F	100 °F	Acrylic Foam	Acrylic Foam	Double Coated Double Sided	0.75 in	0.025 in	General Purpose	Pressure Sensitive Adhesive (PSA)	Gray	300 °F			3 "
3M (TC) 4646-3-9(12)	24 Months	Date of Shipment	40 °F	100 °F	Polyethylene Film	Polyethylene Film	Double Coated Double Sided	3 in	0.025 in		Acrylic	Gray		0.02 in	300 °F	228.6 mm	0.005 in
3M (TC) 3M 4646 7" X 7"-6	24 Months	Date of Shipment	40 °F	100 °F	Polyethylene Film	Polyethylene Film	Double Coated Double Sided	7 in	0.025 in		Acrylic	Gray		0.02 in	300 °F	7 in	0.005 in
3M (TC) 4646-3-6(15)	24 Months	Date of Shipment	40 °F	100 °F	Polyethylene Film	Polyethylene Film	Double Coated Double Sided	3 in	0.025 in		Acrylic	Gray		0.02 in	300 °F	0.5 ft	0.005 in
3M (TC) 3M 4646 0.75" X 1.5"-25	24 Months	Date of Shipment	40 °F	100 °F	Polyethylene Film	Polyethylene Film	Double Coated Double Sided	0.75 in	0.025 in		Acrylic	Gray		0.02 in	300 °F	1.5 in	0.005 in
3M (TC) 4646SQ-1(5)	24 Months	Date of Shipment	40 °F	100 °F	Acrylic Foam	Acrylic Foam	Double Coated Double Sided	1 in	0.025 in	General Purpose	Pressure Sensitive Adhesive (PSA)	Gray	300 °F			25.4 mm
3M (TC) 3.75-5-4646	24 Months	Date of Shipment	40 °F	100 °F	Polyethylene Film	Polyethylene Film	Double Coated Double Sided	3.75 in	0.025 in		Acrylic	Gray		0.02 in	300 °F		0.005 in	5 yd	15 ft
3M (TC) 4646-1.125-5	24 Months	Date of Shipment	40 °F	100 °F	Polyethylene Film	Polyethylene Film	Double Coated Double Sided	1.13 in	0.025 in		Acrylic	Gray		0.02 in	300 °F		0.005 in	5 yd	15 ft

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

4646-0.75-5 | Datasheet
