Specification	2900309

Approval Agency	UL, EAC, DNV, cULus
Coil Current	4.8 mA
Coil Resistance	12.5 kOhms
Coil Type	Non Latching
Coil Voltage	60 VDC
Contact Form	C, 1, SPDT, Form
Contact Material	Gold (Au), Silver Tin Oxide (AgSnO)
Contact Rating (Current)	50 mA
Features	Socket Included, Lighted Indicator
Mounting Type	DIN Rail
Operate Time	5 ms
Operating Temperature (Max)	60 °C
Operating Temperature (Min)	-40 °C
Relay Type	General Purpose
Release Time	8 ms
Switching Voltage AC (Max)	30 VAC
Switching Voltage DC (Max)	36 VDC
Termination Style	Spring Terminal

29003 Series

Part	Release Time	Operating Temperature (Max)	Operating Temperature (Min)	Coil Type	Mounting Type	Contact Form	Contact Material	Contact Rating (Current)	Termination Style	Operate Time	Switching Voltage AC (Max)	Switching Voltage DC (Max)	Coil Current	Approval Agency	Coil Voltage	Features	Relay Type	Coil Resistance	Coil Voltage (Type)
Phoenix Contact 2900338	10 ms	60 °C	-40 °C	Non Latching	DIN Rail	2 2 Form C C DPDT Form	Gold (Au) Silver Nickel (AgNi)	50 mA	Spring Terminal	8 ms	30 VAC	36 VDC	18 mA	cULus DNV EAC UL	24 VDC	Diode Lighted Indicator Socket Included	General Purpose	1.33 kOhms
Phoenix Contact 2900329	10 ms	60 °C	-40 °C	Non Latching	DIN Rail	2 2 Form C C DPDT Form	Silver Nickel (AgNi)	6 A	Spring Terminal	8 ms	250 VAC	250 VDC	33 mA	CE UKCA	12 VAC	Diode Lighted Indicator Socket Included	General Purpose	364 Ohms
Phoenix Contact 2900336	10 ms	55 °C	-40 °C	Non Latching	DIN Rail	2 2 Form C C DPDT Form	Silver Nickel (AgNi)	6 A	Spring Terminal	7 ms	250 VAC	250 VDC	4.5 mA	CE UKCA	230 VDC	Lighted Indicator Socket Included	General Purpose	51.11 kOhms	AC DC
Phoenix Contact 2900301	8 ms	60 °C	-40 °C	Non Latching	DIN Rail	1 C Form SPDT	Silver Tin Oxide (AgSnO)	6 A	Spring Terminal	5 ms	250 VAC	250 VDC	9.2 mA	CE UKCA	48 V	Lighted Indicator Socket Included	General Purpose	5.217 kOhms
Phoenix Contact 2900351	11 ms	70 °C	-40 °C	Non Latching	DIN Rail	2 2 Form C C DPDT Form	Gold (Au) Silver Nickel (AgNi)	50 mA	Screw Terminal	5 ms	30 VAC	36 VDC	4.5 mA	cULus DNV EAC UL	110 V	Diode Lighted Indicator Socket Included	General Purpose	24.44 kOhms
Phoenix Contact 2900310	15 ms	60 °C	-40 °C	Non Latching	DIN Rail	1 C Form SPDT	Gold (Au) Silver Tin Oxide (AgSnO)	50 mA	Spring Terminal	6 ms	30 VAC	36 VDC	3.5 mA	cULus DNV EAC UL	120 V	Lighted Indicator Socket Included	General Purpose	34.29 kOhms	AC DC
Phoenix Contact 2900316	8 ms	60 °C	-40 °C	Non Latching	DIN Rail	1 C Form SPDT	Silver Tin Oxide (AgSnO)	6 A	Spring Terminal	5 ms	250 VAC	250 VDC	15.3 mA	CE UKCA	12 VAC	Lighted Indicator Socket Included	General Purpose	784.3 Ohms
Phoenix Contact 2900318	4 ms	70 °C	-40 °C	Non Latching	DIN Rail	1 C Form SPDT	Silver Tin Oxide (AgSnO)	6 A	Spring Terminal	4 ms	250 VAC	250 VDC	9 mA	CE UKCA	24 VDC	Diode Lighted Indicator Socket Included	General Purpose	2.67 kOhms
Phoenix Contact 2900348	11 ms	70 °C	-40 °C	Non Latching	DIN Rail	2 2 Form C C DPDT Form	Silver Nickel (AgNi)	6 A	Spring Terminal	5 ms	250 VAC	250 VDC	4.5 mA	CE UKCA	110 V	Diode Lighted Indicator Socket Included	General Purpose	24.44 kOhms
Phoenix Contact 2900350	11 ms	70 °C	-40 °C	Non Latching	DIN Rail	2 2 Form C C DPDT Form	Gold (Au) Silver Nickel (AgNi)	50 mA	Screw Terminal	5 ms	30 VAC	36 VDC	6 mA	cULus DNV EAC UL	72 VDC	Diode Lighted Indicator Socket Included	General Purpose	12 kOhms
