ATE 36-1.5DM
ActiveKepco and Kepco Power
POWER SUPPLY RACK MNT 50W LCD
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
ATE 36-1.5DM
ActiveKepco and Kepco Power
POWER SUPPLY RACK MNT 50W LCD
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | ATE 36-1.5DM | ATE 36 Series |
|---|---|---|
| Current - Output [Max] | 1.5 A | 1.5 - 30 A |
| Current - Output [Min] | 0 A | 0 A |
| Display Type | LCD | LCD |
| Features | Programmable | Programmable, GPIB Interface |
| Number of Characters | 3.5 | 3.5 |
| Number of Characters | 2 | 2 |
| Power (Watts) | 50 W | 1 - 100 kW |
| Ripple | 30 mV, 10 mV | 10 - 30 mV |
| Size / Dimension | - | 6.969 " |
| Size / Dimension | - | 19 in |
| Size / Dimension | - | 19.874 in |
| Size / Dimension [x] | 435 mm | 435 mm |
| Size / Dimension [x] | 17.126 in | 17.126 - 504.8 mm |
| Size / Dimension [y] | 132.6 mm | 132.6 mm |
| Size / Dimension [y] | 5.22 " | 5.22 - 482.6 mm |
| Size / Dimension [z] | 4.157 in | 4.157 - 177 mm |
| Size / Dimension [z] | 105.6 mm | 105.6 mm |
| Type | Rack Mount (AC to DC) | Rack Mount (AC to DC) |
| Voltage - Output [Max] | 36 V | 36 V |
| Voltage - Output [Min] | 0 VDC | 0 VDC |
| Voltage - Supply [Max] | 250 VAC | 250 VAC |
| Voltage - Supply [Min] | 95 VAC | 95 VAC |
ATE 36 Series
POWER SUPPLY RACK MNT 1000W LCD
| Part | Voltage - Output [Min] | Voltage - Output [Max] | Voltage - Supply [Min] | Voltage - Supply [Max] | Display Type | Ripple | Number of Characters | Number of Characters | Features | Type | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Current - Output [Min] | Current - Output [Max] | Power (Watts) | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Kepco and Kepco Power ATE 36-30DMG | 0 VDC | 36 V | 95 VAC | 250 VAC | LCD | 10 mV, 30 mV | 3.5 | 2 | GPIB Interface, Programmable | Rack Mount (AC to DC) | 504.8 mm | 6.969 " | 177 mm | 482.6 mm | 19 in | 19.874 in | 0 A | 30 A | 1 kW | |||
Kepco and Kepco Power ATE 36-3DM | 0 VDC | 36 V | 95 VAC | 250 VAC | LCD | 10 mV, 30 mV | 3.5 | 2 | Programmable | Rack Mount (AC to DC) | 17.126 in | 4.157 in | 5.22 " | 0 A | 3 A | 100 W | 132.6 mm | 435 mm | 105.6 mm | |||
Kepco and Kepco Power ATE 36-1.5DM | 0 VDC | 36 V | 95 VAC | 250 VAC | LCD | 10 mV, 30 mV | 3.5 | 2 | Programmable | Rack Mount (AC to DC) | 17.126 in | 4.157 in | 5.22 " | 0 A | 1.5 A | 50 W | 132.6 mm | 435 mm | 105.6 mm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 2639.25 | |
Description
General part information
ATE 36 Series
0 ~ 36VDC Output Rack Mount (AC to DC) Power Supply LCD 0 ~ 1.5A Output 50W Features Programmable
