Description
General part information
AM1DR-1515SJZ
Isolated Module DC DC Converter 1 Output 15V 67mA 14.25V - 15.75V Input
Technical Specifications
Parameters and characteristics for this part
| Specification | AM1DR-1515SJZ |
|---|---|
| Applications | ITE (Commercial) |
| Current - Output (Max) | 67 mA |
| Efficiency | 75 % |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Package Leads | 4 Leads |
| Package Name | 7-SIP Module |
| Power (Watts) | 1 W |
| Size / Dimension Height | 0.4 in |
| Size / Dimension Length | 0.77 in |
| Size / Dimension Width | 0.24 in |
| Type | Isolated Module |
| Voltage - Input (Max) | 15.75 V |
| Voltage - Input (Min) | 14.25 V |
| Voltage - Isolation | 1500 Vrns |
| Voltage - Output 1 | 15 V |
