Part	Insulation	Wire Gauge	Termination	Number of Wire Entries	Terminal Type	Wire Gauge (AWG) (Min)	Wire Gauge (AWG) (Max)	Color	Features	Diameter - Ring ID	Contact Material	Contact Finish	Tab Thickness	Width - Outer Edges	Stud/Tab Size	Length - Overall	Mounting Type	Terminal Style	Length - Ring Center to Termination	Tongue Inside Opening	Insulation Diameter (Min)	Insulation Diameter (Max)	Material - Insulation	Length - Termination	Insulation Diameter	Stud/Tab Size (Type)	Stud/Tab Size	Thickness
TE Connectivity AMP Connectors 328596	Non-Insulated	14 AWG	Crimp	2	Butt Splice Individual Openings Inline
TE Connectivity AMP Connectors 328569	Fully Insulated		Crimp	2	Butt Splice Individual Openings Inline	8 AWG	12 AWG	Red Yellow	Step Up/Step Down
TE Connectivity AMP Connectors 328500	Non-Insulated		Crimp		Rectangular Tongue	16 AWG	22 AWG		Serrated Termination	0.132 in	Copper	Tin	0.031 in	0.277 in	5 Stud	0.786 in	Free Hanging (In-Line)	Single Stud Hole
TE Connectivity AMP Connectors 328588	Non-Insulated		Crimp	2	Butt Splice Individual Openings Inline	19.5 AWG	24 AWG		Brazed Seam Serrated Mating Area
TE Connectivity AMP Connectors 328516	Insulated		Crimp		Flanged	16 AWG	22 AWG	Red	Serrated Termination		Copper	Tin		0.296 in	10 Stud	0.78 in	Free Hanging (In-Line)		0.203 in	0.197 in	0.105 in	0.14 in	Poly-Vinyl Chloride PVC	0.416 in
TE Connectivity AMP Connectors 328592	Non-Insulated		Crimp	2	Butt Splice Individual Openings Inline	16 AWG	18 AWG		Serrated Mating Area
TE Connectivity AMP Connectors 328525	Insulated	8 AWG	Crimp		Circular			Red	Serrated Termination		Copper	Tin		0.587 in	0.3125 in	1.702 in	Free Hanging (In-Line)						Vinyl		0.377 in	Stud	16 Stud 5 Stud	0.04 in
