SC3340F-331
ActiveSignal Transformer
FIXED IND 330UH 1A 700 MOHM SMD
SC3340F-331
ActiveSignal Transformer
FIXED IND 330UH 1A 700 MOHM SMD
Description
General part information
SC3340F-331
330 µH Unshielded Wirewound Inductor 1 A 700mOhm Max Nonstandard
Technical Specifications
Parameters and characteristics for this part
| Specification | SC3340F-331 |
|---|---|
| Current - Saturation (Isat) | 1.2 A |
| Current Rating | 1 A |
| DC Resistance (DCR) (Max) | 700 mOhm |
| Height - Seated (Max) | 0.45 in |
| Inductance | 330 µH |
| Inductance Frequency - Test | 100 kHz |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Nonstandard |
| Shielding | Unshielded |
| Size / Dimension Length | 0.53 in |
| Size / Dimension Width | 0.39 in |
| Tolerance | 20 % |
| Type | Wirewound |
