1087142
ActivePhoenix Contact
FIB OPT CBL M17-M17 MULT 170M
1087142
ActivePhoenix Contact
FIB OPT CBL M17-M17 MULT 170M
Description
General part information
1087142
Cable Fiber Optic M17 To M17 62.5/125 557.7' (170.0m)
Technical Specifications
Parameters and characteristics for this part
| Specification | 1087142 |
|---|---|
| 1st Connector | M17 |
| 2nd Connector | M17 |
| Bend Radius | 80 mm |
| Cable Diameter | 0.3 " |
| Color - Cable | Black |
| Color - Connectors | Silver |
| Fiber Cladding Diameter | 125 µm |
| Fiber Core Diameter | 62.5 µm |
| Jacket (Insulation) Material | Low Smoke Zero Halogen (LSZH) |
| Length - Overall | 557.7 ft |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Ratings | LSZH |
| Type | OM1, Multimode |
