ZFL-500LNB+
ActiveMini-Circuits
LNA, 0.1 - 500 MHZ, 50
ZFL-500LNB+
ActiveMini-Circuits
LNA, 0.1 - 500 MHZ, 50
Description
General part information
ZFL-500LNB+
RF Amplifier IC UHF, VHF 100kHz ~ 500MHz
Technical Specifications
Parameters and characteristics for this part
| Specification | ZFL-500LNB+ |
|---|---|
| Current - Supply | 60 mA |
| Frequency Range 1 (Max) | 500 MHz |
| Frequency Range 1 (Min) | 100 kHz |
| Gain | 24 dB |
| Mounting Type | Chassis Mount |
| Noise Figure | 2.9 dB |
| P1dB | 5 dBm |
| Package / Case | Module, SMA Connectors |
| RF Type | UHF, VHF |
| Test Frequency (Maximum) | 500 MHz |
| Test Frequency (Minimum) | 100 kHz |
| Voltage - Supply | 15 VDC |
