3-2316108-8
ActiveTE Connectivity AMP Connectors
HEADERS & WIRE HOUSINGS 38P,2MM,REC,HSG,DR ,CRIMP,PLAIN,BOX
3-2316108-8
ActiveTE Connectivity AMP Connectors
HEADERS & WIRE HOUSINGS 38P,2MM,REC,HSG,DR ,CRIMP,PLAIN,BOX
Description
General part information
3-2316108-8
HEADERS & WIRE HOUSINGS 38P,2MM,REC,HSG,DR ,CRIMP,PLAIN,BOX
Technical Specifications
Parameters and characteristics for this part
| Specification | 3-2316108-8 |
|---|---|
| Color | Black |
| Connector Type | Receptacle |
| Contact Termination | Crimp |
| Contact Type | Female Socket |
| Fastening Type | Push-Pull |
| Insulation Material | Liquid Crystal Polymer (LCP) |
| Mounting Type | Free Hanging (In-Line) |
| Number of Positions | 38 |
| Number of Rows | 2 |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Pitch | 0.079 in |
| Row Spacing | 0.079 in |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
