RM042C225KAJ240
ActiveKYOCERA AVX
CAP CER 2.2UF 200V X7R SMD
RM042C225KAJ240
ActiveKYOCERA AVX
CAP CER 2.2UF 200V X7R SMD
Description
General part information
RM042C225KAJ240
2.2 µF ±10% 200V Ceramic Capacitor X7R Stacked SMD, 8 J-Lead
Technical Specifications
Parameters and characteristics for this part
| Specification | RM042C225KAJ240 |
|---|---|
| Applications | Bypass, Decoupling |
| Capacitance | 2.2 µF |
| Features | Low ESL (Stacked) |
| Lead Style | J-Lead |
| Mounting Type | Surface Mount, MLCC |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package Leads | 8 Leads |
| Package Name | Stacked SMD |
| Size / Dimension Length | 0.402 in |
| Size / Dimension Width | 0.441 in |
| Temperature Coefficient | X7R |
| Thickness (Max) | 0.32 in |
| Tolerance | 10 % |
| Voltage - Rated | 200 VDC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
