PM2277NLT
ActivePulse Electronics
XFMR FLYBACK DC/DC CONV SMD
PM2277NLT
ActivePulse Electronics
XFMR FLYBACK DC/DC CONV SMD
Description
General part information
PM2277NLT
Flyback Converters For For DC/DC Converters SMPS Transformer 2500V Isolation 51 ~ 69kHz Surface Mount
Technical Specifications
Parameters and characteristics for this part
| Specification | PM2277NLT |
|---|---|
| Applications | Flyback Converters |
| Chipset Manufacturer | Broadcom, ROHM |
| Frequency (Max) | 69 kHz |
| Frequency (Min) | 51 Hz |
| Height - Seated (Max) | 12.7 mm |
| Intended Chipset | ACPL-32JT, ACPL-302J |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Size / Dimension Length | 0.433 in |
| Size / Dimension Width | 0.433 in |
| Style | Laminated Core |
| Type | For DC/DC Converters |
| Voltage - Isolation | 2500 Vrms |
| Voltage - Primary (Max) | 18 V |
| Voltage - Primary (Min) | 8 V |
