IQE24009A120V-001-R
ObsoleteTDK Corporation
DC DC CONVERTER 12V
IQE24009A120V-001-R
ObsoleteTDK Corporation
DC DC CONVERTER 12V
Description
General part information
IQE24009A120V-001-R
Isolated Module DC DC Converter 1 Output 12V 9A 18V - 36V Input
Technical Specifications
Parameters and characteristics for this part
| Specification | IQE24009A120V-001-R |
|---|---|
| Applications | ITE (Commercial) |
| Control Features | Enable, Active Low |
| Current - Output (Max) | 9 A |
| Efficiency | 90 % |
| Features | OCP, OVP, Remote On/Off |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | 8-DIP Module, 1/4 Brick |
| Size / Dimension Height | 0.39 in |
| Size / Dimension Length | 2.28 in |
| Size / Dimension Width | 1.45 in |
| Type | Isolated Module |
| Voltage - Input (Max) | 36 V |
| Voltage - Input (Min) | 18 V |
| Voltage - Isolation | 1500 Vrns |
| Voltage - Output 1 | 12 V |
