284415-5
ActiveTE Connectivity AMP Connectors
TERM BLK 5POS TOP ENT 3.81MM PCB
284415-5
ActiveTE Connectivity AMP Connectors
TERM BLK 5POS TOP ENT 3.81MM PCB
Description
General part information
284415-5
5 Position PCB Terminal Block, Header, Wire-to-Board, 3.81 mm [.15 in] Centerline, 1 Row, 90° Wire Entry Angle, 30 – 14 AWG, .05 – 2 mm² Wire, 300 VAC
Technical Specifications
Parameters and characteristics for this part
| Specification | 284415-5 |
|---|---|
| Color | Green |
| Current | 12 A |
| Features | Interlocking (Side) |
| Mating Orientation | Vertical with Board |
| Mounting Type | Through Hole |
| Number of Levels | 1 |
| Pitch | 0.15 in |
| Positions Per Level | 5 |
| Voltage | 300 V |
| Wire Gauge (AWG) (Max) | 30 AWG |
| Wire Gauge (AWG) (Min) | 12 AWG |
| Wire Termination | Rising Cage Clamp, Screw |
