RM35TF30SP01
ObsoleteSCHNEIDER ELECTRIC
MULTIFUNCTION PHASE CONTROL RELA
RM35TF30SP01
ObsoleteSCHNEIDER ELECTRIC
MULTIFUNCTION PHASE CONTROL RELA
Description
General part information
RM35TF30SP01
Voltage Asymmetry, Voltage Sensing AC, Phase Loss, Phase Sequence
Technical Specifications
Parameters and characteristics for this part
| Specification | RM35TF30SP01 |
|---|---|
| Circuit | DPDT (2 Form C) |
| Contact Rating (Current) | 5 A |
| Delay Time (Maximum) | 10 Sec |
| Delay Time (Minimum) | 0.1 Sec |
| Mounting Type | DIN Rail |
| Operating Temperature (Max) | 50 °C |
| Operating Temperature (Min) | -20 °C |
| Output Type | Relay |
| Trip Status | Low, Energized High |
| Trip Voltage (Max) | 528 V |
| Trip Voltage (Min) | 194 V |
| Type | Phase Sequence, Voltage Asymmetry, Phase Loss, Voltage Sensing AC |
| Voltage Rating | 250VAC, 250VDC |
