TPAN0263F33R0K9
ActiveC&B Eureka Innovations
RES 33 OHMS 50W 1% TO263
TPAN0263F33R0K9
ActiveC&B Eureka Innovations
RES 33 OHMS 50W 1% TO263
Description
General part information
TPAN0263F33R0K9
33 Ohms ±1% 50W Chip Resistor TO-263-3, D2PAK (2 Leads + Tab), TO-263AB Automotive AEC-Q200, Non-Inductive Thick Film
Technical Specifications
Parameters and characteristics for this part
| Specification | TPAN0263F33R0K9 |
|---|---|
| Composition | Thick Film |
| Features | Non-Inductive, Automotive AEC-Q200 |
| Height - Seated (Max) | 0.189 in |
| Number of Terminations | 2 |
| Operating Temperature (Max) | 150 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | D2PAK (2 Leads + Tab), TO-263-3, TO-263AB |
| Package Name | TO-263 |
| Power (Watts) | 50 W |
| Ratings | AEC-Q200 |
| Resistance | 33 Ohms |
| Size / Dimension Length | 0.398 in |
| Size / Dimension Width | 0.307 in |
| Temperature Coefficient | 100 ppm/°C |
| Tolerance | 1 % |
