Description
General part information
SET 5A 125V (G)
5 A 125 V AC 125 V DC Fuse Board Mount (Cartridge Style Excluded) Surface Mount 2-SMD, Square End Block
Technical Specifications
Parameters and characteristics for this part
| Specification | SET 5A 125V (G) |
|---|---|
| Approval Agency | CSA, cURus, PSE |
| Breaking Capacity | 50 A |
| Current Rating | 5 A |
| DC Cold Resistance | 0.013 Ohms |
| Fuse Type | Board Mount (Cartridge Style Excluded) |
| Melting I²t | 54.8 |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | 2-SMD, Square End Block |
| Response Time | Slow Blow |
| Size / Dimension Height | 0.102 in |
| Size / Dimension Length | 0.24 in |
| Size / Dimension Width | 0.102 in |
| Voltage Rating - AC | 125 V |
| Voltage Rating - DC | 125 V |
