WTX0614H2R2LT
ActiveShenzhen Sunlord Electronics Co., Ltd.
FIXED IND 2.215%UH 0.030OHM 6600
WTX0614H2R2LT
ActiveShenzhen Sunlord Electronics Co., Ltd.
FIXED IND 2.215%UH 0.030OHM 6600
Description
General part information
WTX0614H2R2LT
2.2 µH Unshielded Wirewound Inductor 2424 (6060 Metric)
Technical Specifications
Parameters and characteristics for this part
| Specification | WTX0614H2R2LT |
|---|---|
| Height - Seated (Max) | 0.055 in |
| Inductance | 2.2 µH |
| Inductance Frequency - Test | 1 MHz |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 155 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | 2424 (6060 Metric) |
| Package Name | 2424 |
| Shielding | Unshielded |
| Size / Dimension Length | 0.236 in |
| Size / Dimension Width | 0.236 in |
| Tolerance | 15 % |
| Type | Wirewound |
