EV-ADF4401ASD2Z
ActiveEVALUATION BOARD, ADF4401AJCCZ, PLL, VCO MODULE, TRANSLATION LOOP
EV-ADF4401ASD2Z
ActiveEVALUATION BOARD, ADF4401AJCCZ, PLL, VCO MODULE, TRANSLATION LOOP
Description
General part information
EV-ADF4401ASD2Z
EV-ADF4401ASD2Z is an evaluation board to evaluate the ADF4401A translation loop, PLL, VCO module. The EV-ADF4401ASD2Z contains the ADF4401A integrated SiP, phase frequency detector (PFD), active loop filter, power supply connectors and Subminiature Version A (SMA) connectors. The EV-ADF4401ASD2Z requires an EVAL-SDP-CS1Z (SDP-S) system demonstration platform (SDP) which allows software programming of the EV-ADF4401ASD2Z.
Technical Specifications
Parameters and characteristics for this part
| Specification | EV-ADF4401ASD2Z |
|---|---|
| Contents | Board |
| For Use With/Related Products | ADF4401A |
| Frequency Range 1 (Max) | 8 GHz |
| Frequency Range 1 (Min) | 62.5 MHz |
| Supplied Contents | Board(s) |
| Type | Voltage Controlled Oscillator (VCO) |
| Utilized IC / Part | ADF4401A |
