2P1515
ActiveSWITCHCRAFT/CONXALL
CONN PWR PLUG 2.5X5.5MM SOLDER
2P1515
ActiveSWITCHCRAFT/CONXALL
CONN PWR PLUG 2.5X5.5MM SOLDER
Description
General part information
2P1515
Power Barrel Connector Plug 2.50mm ID (0.098"), 5.50mm OD (0.217") Free Hanging (In-Line)
Technical Specifications
Parameters and characteristics for this part
| Specification | 2P1515 |
|---|---|
| Actual Diameter (ID) | 0.098 in |
| Actual Diameter (OD) | 0.217 in |
| Body Color | Silver |
| Connector Type | Plug |
| Contact Material | Copper Alloy |
| Contact Material - Plating | Tin |
| Gender | Female |
| Industry Recognized Mating Diameter (ID) | 2.5 mm |
| Industry Recognized Mating Diameter (OD) | 5.5 mm |
| Insulation Color | Black |
| Internal Switch(s) | Does Not Contain Switch |
| Mating Length/Depth | 0.374 in |
| Mounting Type | Free Hanging (In-Line) |
| Number of Conductors | 2 Conductors |
| Number of Contacts | 2 Contacts |
| Shielding | Unshielded |
| Termination | Solder Eyelet(s) |
