Description
General part information
RT0402FRE0776K8L
76.8 kOhms ±1% 0.063W, 1/16W Chip Resistor 0402 (1005 Metric) Thin Film
Technical Specifications
Parameters and characteristics for this part
| Specification | RT0402FRE0776K8L |
|---|---|
| Composition | Thin Film |
| Height - Seated (Max) | 0.014 in |
| Number of Terminations | 2 |
| Operating Temperature (Max) | 155 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | 0402 (1005 Metric) |
| Package Name | 0402 |
| Power (Watts) | 0.063 W |
| Power (Watts) Options | 1/16W |
| Resistance | 76.8 kOhm |
| Size / Dimension Length | 0.039 in |
| Size / Dimension Width | 0.02 in |
| Temperature Coefficient | 50 ppm/°C |
| Tolerance | 1 % |
