XS9C4A2A1G13
ActiveINDUCTIVE PROXIMITY SENSOR, RECTANGULAR, OSISENSE XS, NON FLUSH, 25 MM, CURRENT, 12-24V, PG13
XS9C4A2A1G13
ActiveINDUCTIVE PROXIMITY SENSOR, RECTANGULAR, OSISENSE XS, NON FLUSH, 25 MM, CURRENT, 12-24V, PG13
Description
General part information
XS9C4A2A1G13
The XS9C4A2A1G13 is a 3-wire Inductive Proximity Sensor with analogue output. Form 40 x 40 x 117 sensor. 1 LED yellow for output status. PBT enclosure. 24VDC with reverse polarity protection. IP69K conforming to DIN 40050, IP65 conforming to IEC 60529 and IP67 conforming to IEC 60529.
Technical Specifications
Parameters and characteristics for this part
| Specification | XS9C4A2A1G13 |
|---|---|
| Indicator | LED |
| Ingress Protection | IP67, IP65, IP69K |
| Material - Body | Polybutylene Terephthalate (PBT) |
| Operating Temperature (Max) | 70 °C |
| Operating Temperature (Min) | -25 °C |
| Output Type | Analog Voltage |
| Package / Case | Module |
| Sensing Distance | 0.984 " |
| Sensor Type | Inductive |
| Shielding | Unshielded |
| Termination Style | Screw Terminal |
| Voltage - Supply | 24 VDC |
