1607630
LTBPhoenix Contact
CONN RCPT HSG MALE 17POS INLINE
1607630
LTBPhoenix Contact
CONN RCPT HSG MALE 17POS INLINE
Description
General part information
1607630
17 Position Circular Connector Receptacle Housing Free Hanging (In-Line) Backshell
Technical Specifications
Parameters and characteristics for this part
| Specification | 1607630 |
|---|---|
| Connector Type | Receptacle Housing |
| Contact Shape | Circular |
| Contact Size | 0.6 mm |
| Contact Type | Crimp |
| Fastening Type | Push-Twist |
| Features | Backshell |
| Housing Color | Silver |
| Ingress Protection Description | Waterproof, Dust Tight |
| Ingress Protection IP Rating | IP67 |
| Insert Material | Polyamide, Nylon 6/6, PA66 |
| Mounting Type | Free Hanging (In-Line) |
| Note | Contacts Not Included |
| Number of Positions | 17 |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Orientation | N (Normal) |
| Shell Material | Gadolinium-Zinc |
| Shell Size - Insert | M17-17 |
| Shielding | Shielded |
| Type | For Male Pins |
