Specification	CUS30M-12/SF

Applications	Medical, ITE (Commercial), Household Appliances
Approval Agency	CE
Current - Output 1	2.5 A
Efficiency	88 %
Features	Universal Input, Adjustable Output
Mounting Type	Chassis Mount
Number of Outputs	1
Operating Temperature (Max)	70 °C
Operating Temperature (Min)	-20 °C
Power (Watts)	30 W
Size / Dimension Height	0.85 in
Size / Dimension Length	3 in
Size / Dimension Width	2 in
Type	Open Frame
Voltage - Input (AC) Maximum	265 VAC
Voltage - Input (AC) Minimum	85 VAC
Voltage - Isolation	4000 Vpk
Voltage - Output 1	12 V

CUS30M Series

Part	Power (Watts)	Current - Output 1	Applications	Mounting Type	Voltage - Output 1	Size / Dimension Length	Size / Dimension Width	Size / Dimension Height	Voltage - Input (AC) Maximum	Voltage - Input (AC) Minimum	Number of Outputs	Approval Agency	Operating Temperature (Max)	Operating Temperature (Min)	Voltage - Isolation	Type	Efficiency	Features	Package / Case	Current - Output (Max)	Load Regulation (mV)	Line Regulation
TDK Corporation CUS30M-24/M	30 W	1.25 A	Household Appliances ITE (Commercial) Medical	Chassis Mount	24 V	3 in	2 in	0.85 in	265 VAC	85 VAC	1	CE	70 °C	-20 °C	4000 Vpk	Open Frame	90 %	Adjustable Output Universal Input
TDK Corporation CUS30M-12/A	30 W	2.5 A	Household Appliances ITE (Commercial) Medical	Chassis Mount	12 V	3.48 in	2.52 in	1.4 in	265 VAC	85 VAC	1	CE	70 °C	-20 °C	4000 Vpk	Enclosed	88 %	Adjustable Output Universal Input
TDK Corporation CUS30M-24/SF	30 W	1.25 A	Household Appliances ITE (Commercial) Medical	Chassis Mount	24 V	3 in	2 in	0.85 in	265 VAC	85 VAC	1	CE	70 °C	-20 °C	4000 Vpk	Open Frame	90 %	Adjustable Output Universal Input
TDK Corporation CUS30M-18/SF	31 W	1.7 A	Household Appliances ITE (Commercial) Medical	Chassis Mount	18 V	3 in	2 in	0.85 in	265 VAC	85 VAC	1	CE	70 °C	-20 °C	4000 Vpk	Open Frame	88 %	Adjustable Output Universal Input
TDK Corporation CUS30M-15/SF	30 W	2 A	Household Appliances ITE (Commercial) Medical	Chassis Mount	15 V	3 in	2 in	0.85 in	265 VAC	85 VAC	1	CE	70 °C	-20 °C	4000 Vpk	Open Frame	88 %	Adjustable Output Universal Input
TDK Corporation CUS30M-15/P	30 W		Household Appliances ITE (Commercial) Medical	Through Hole	15 V	3 in	2 in	0.85 in	265 VAC	85 VAC	1	CE	70 °C	-20 °C		Open Frame	88 %	Adjustable Output Universal Input	6-DIP Module	2 A	120 mV	60 mV
TDK Corporation CUS30M-48/P	30 W		Household Appliances ITE (Commercial) Medical	Through Hole	48 V	3 in	2 in	0.85 in	265 VAC	85 VAC	1	CE	70 °C	-20 °C		Open Frame	90 %	Adjustable Output Universal Input	6-DIP Module	630 mA	384 mV	192 mV
TDK Corporation CUS30M-36/P	30 W		Household Appliances ITE (Commercial) Medical	Through Hole	36 V	3 in	2 in	0.85 in	265 VAC	85 VAC	1	CE	70 °C	-20 °C		Open Frame	90 %	Adjustable Output Universal Input	6-DIP Module	840 mA	288 mV	144 mV
TDK Corporation CUS30M-15	30 W	2 A	ITE (Commercial) Medical	Chassis Mount	15 V	3 in	2 in	0.95 in	265 VAC	85 VAC	1	CE	70 °C	-20 °C	4000 Vpk	Open Frame	88 %	PFC Remote Sense
TDK Corporation CUS30M-48/CO	30 W	630 mA	Household Appliances ITE (Commercial) Medical	Chassis Mount	48 V	3 in	2 in	0.85 in	265 VAC	85 VAC	1	CE	70 °C	-20 °C	4000 Vpk	Conformal Coated Open Frame	90 %	Adjustable Output Universal Input
