Description
General part information
COM-12703
Connector Header Surface Mount, Right Angle 3 position 0.100" (2.54mm)
Technical Specifications
Parameters and characteristics for this part
| Specification | COM-12703 |
|---|---|
| Connector Type | Header |
| Contact Shape | Square |
| Contact Type | Male Pin |
| Fastening Type | Push-Pull |
| Insulation Color | Black |
| Mounting Type | Right Angle, Surface Mount |
| Number of Positions | 3 |
| Number of Positions Loaded | All |
| Number of Rows | 1 |
| Pitch - Mating | 0.1 in |
| Shrouding | Unshrouded |
| Style | Board |
| Termination | Solder |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
No documents available
