Specification	139159003101916

Connector Type	Plug
Contact Finish	Gold
Contact Material	Copper Alloy
Current Rating (Per Contact)	5 A
Features	Solder Retention, Pick and Place Cap
Housing Color	White
Housing Material	Nylon, Polyamide, PA
Mating Cycles	10 cycles
Mounting Type	Surface Mount
Number of Positions	3
Operating Temperature (Max)	125 °C
Operating Temperature (Min)	-40 °C
Pitch	0.118 in
Style	Cable/Wire, Board
Termination	Solder
Voltage Rating	125 V

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Technical documentation and resources
