MCP33141-10-E/MN
ActiveMicrochip Technology
12-BIT, 1 MSPS, SINGLE CHANNEL, SINGLE-ENDED SAR ADC 10 TDFN 3X3X0.8MM TUBE ROHS COMPLIANT: YES
MCP33141-10-E/MN
ActiveMicrochip Technology
12-BIT, 1 MSPS, SINGLE CHANNEL, SINGLE-ENDED SAR ADC 10 TDFN 3X3X0.8MM TUBE ROHS COMPLIANT: YES
Description
General part information
MCP33141 Series
The MCP33141D-05 12-bit
Analog-to-Digital Converter (ADC) features a differential input, high
performance and low power consumption in a small package, making it ideal for
Technical Specifications
Parameters and characteristics for this part
| Specification | MCP33141-10-E/MN |
|---|---|
| Architecture | SAR |
| Configuration | ADC |
| Data Interface | SPI |
| Grade | Automotive |
| Input Type | Single Ended |
| Mounting Type | Surface Mount |
| Number of A/D Converters | 1 count |
| Number of Bits | 12 bits |
| Number of Inputs | 1 |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | 10-WFDFN Exposed Pad |
| Package Length | 3 mm |
| Package Name | 10-TDFN |
| Package Width | 3 mm |
| Qualification | AEC-Q100 |
| Ratio - ADC | 1 |
| Ratio - S/H | 0 |
| Reference Type | External |
| Sampling Rate (Per Second) | 1 MHz |
| Voltage - Supply, Analog (Max) | 1.9 V |
| Voltage - Supply, Analog (Min) | 1.7 V |
| Voltage - Supply, Digital (Max) | 5.5 V |
| Voltage - Supply, Digital (Min) | 1.7 V |
