6LS331KNECM
ObsoleteKYOCERA AVX
CAP CER 330PF 2KV Y5P RADIAL
6LS331KNECM
ObsoleteKYOCERA AVX
CAP CER 330PF 2KV Y5P RADIAL
Description
General part information
6LS331KNECM
330 pF ±10% 2000V (2kV) Ceramic Capacitor Y5P (B) Radial, Disc
Technical Specifications
Parameters and characteristics for this part
| Specification | 6LS331KNECM |
|---|---|
| Applications | General Purpose |
| Capacitance | 330 pF |
| Height - Seated (Max) | 0.157 in |
| Lead Spacing | 0.197 in |
| Lead Style | Formed Leads |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Disc, Radial |
| Size / Dimension Diameter | 0.315 in |
| Temperature Coefficient | Y5P (B) |
| Tolerance | 10 % |
| Voltage - Rated | 2000 VAC |
