Description
General part information
RC0201FR-1375KL
RES THICK FILM 0201 75K OHM 1% 0.05W(1/20W) ±200PPM/°C PAD SMD T/R
Technical Specifications
Parameters and characteristics for this part
| Specification | RC0201FR-1375KL |
|---|---|
| Composition | Thick Film |
| Features | Moisture Resistant |
| Height - Seated (Max) | 0.01 in |
| Number of Terminations | 2 |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | 0201 (0603 Metric) |
| Package Name | 0201 |
| Power (Watts) | 50 mW |
| Power (Watts) Options | 1/20W |
| Resistance | 75 kOhm |
| Size / Dimension Length | 0.024 in |
| Size / Dimension Width | 0.012 in |
| Temperature Coefficient | 200 ppm/°C |
| Tolerance | 1 % |
