Specification	D38999/26LG39SN

Applications	Military, Aviation, Marine
Color	Silver
Connector Type	Female Sockets, Plug
Contact Finish - Mating	Gold
Fastening Type	Threaded
Features	Self Locking
Grade	Military
Ingress Protection	Weathertight
Material Flammability Rating	UL94 V-0
Mounting Type	Free Hanging (In-Line)
Number of Positions	39
Operating Temperature (Max)	150 °C
Operating Temperature (Min)	-65 °C
Orientation	N (Normal)
Qualification	MIL-DTL-38999 Series II
Shell Size - Insert (Maximum)	39
Shell Size - Insert (Minimum)	21
Shell Size (MIL)	G
Shielding	Unshielded
Termination	Crimp
Voltage Rating	500 V

D38999/26LG Series

Part	Connector Type	Termination	Fastening Type	Mounting Type	Contact Finish - Mating	Orientation	Applications	Color	Number of Positions	Shell Size (MIL)	Shell Size - Insert Length	Shell Size - Insert Width	Shielding	Shell Size - Insert (Maximum)	Shell Size - Insert (Minimum)	Type	Contact Type	Primary Material	Material Flammability Rating	Qualification	Voltage Rating	Ingress Protection	Operating Temperature (Min)	Operating Temperature (Max)	Features	Grade	Insert Material	Contact Material
Amphenol Aerospace Operations D38999/26LG16HN	Male Pins Plug	Crimp	Threaded	Free Hanging (In-Line)	Gold	N (Normal)	Aviation Marine Military	Silver	16	G	21 mm	16 mm	Unshielded
Amphenol Aerospace Operations D38999/26LG11SNL
Amphenol Aerospace Operations D38999/26LG35JN	Female Sockets Plug	Crimp	Threaded	Free Hanging (In-Line)	Gold	N (Normal)	Aviation Marine Military	Silver	79	G			Unshielded	35	21
Amphenol Aerospace Operations D38999/26LG41PNL	Plug Housing		Threaded	Free Hanging (In-Line)		N (Normal)			41	G						For Male Pins	Crimp	Metal
Amphenol Aerospace Operations D38999/26LG41PN	Male Pins Plug	Crimp	Threaded	Free Hanging (In-Line)	Gold	N (Normal)	Aviation Marine Military	Silver	41	G			Unshielded	41	21				UL94 V-0	MIL-DTL-38999 Series II	500 V	Weathertight	-65 °C	150 °C	Self Locking	Military
Amphenol Aerospace Operations D38999/26LG11SN	Female Sockets Plug	Crimp	Threaded	Free Hanging (In-Line)	Gold	N (Normal)	Aviation Marine Military	Silver	11	G	21 mm	11 mm	Unshielded
Amphenol Aerospace Operations D38999/26LG39SNL	Receptacle Housing		Threaded	Free Hanging (In-Line)		N (Normal)			39	G						For Female Sockets	Crimp	Metal
Amphenol Aerospace Operations D38999/26LG16PNL
Amphenol Aerospace Operations D38999/26LG41HN	Male Pins Plug	Crimp	Threaded	Free Hanging (In-Line)	Gold	N (Normal)	Aviation Marine Military	Silver	41	G			Unshielded	41	21
Amphenol Aerospace Operations D38999/26LG16PN	Male Pins Plug	Crimp	Threaded	Free Hanging (In-Line)	Gold	N (Normal)	Aerospace Aviation Marine Military	Silver	16	G	21 mm	16 mm	Unshielded						UL94 V-0	MIL-DTL-38999 Series II	500 V	Weathertight	-65 °C	150 °C	Self Locking	Military	Thermoplastic	Copper Alloy
