0.5 pitch, 26pin, Vertical, GF, SMT-2-2495219-6

2-2495219-6

Active
TE Connectivity AMP Connectors

0.5 PITCH, 26PIN, VERTICAL, GF, SMT

Find alt
0.5 pitch, 26pin, Vertical, GF, SMT-2-2495219-6

2-2495219-6

Active
TE Connectivity AMP Connectors

0.5 PITCH, 26PIN, VERTICAL, GF, SMT

Find alt

Description

General part information

2-2495219-6

.5 mm Centerline, Right Angle, Surface Mount, Stuffer Actuator, Gold Flash, 26 Position, FPC Connectors

Technical Specifications

Parameters and characteristics for this part

Specification2-2495219-6
Actuator MaterialNylon 9T, Polyamide (PA9T)
Cable End TypeStraight
Connector/Contact TypeContacts, Bottom
Contact FinishGold
Contact MaterialPhosphor Bronze
FeaturesZero Insertion Force (ZIF)
FFC, FCB Thickness0.3 mm
Flat Flex TypeFPC
Height Above Board0.039 in
Housing MaterialLiquid Crystal Polymer, LCP
Material Flammability RatingUL94 V-0
Mounting TypeRight Angle, Surface Mount
Number of Positions26
Operating Temperature (Max)85 °C
Operating Temperature (Min)-40 °C
Pitch0.02 in
TerminationSolder
Voltage Rating50 V
