LC2K1210F7
ActiveCONTACTOR, 12 A, PANEL MOUNT, 600 VAC, 3PST-NO, 3 POLE, 10 HP
LC2K1210F7
ActiveCONTACTOR, 12 A, PANEL MOUNT, 600 VAC, 3PST-NO, 3 POLE, 10 HP
Description
General part information
LC2K1210F7
The LC2K1210F7 is a TeSys™ K-line Reversing Mini-contactor with 3PST (3NO) contacts and screw clamp connection. This panel mount contactor features preassembled with reversing power bus bar device. The low consumption DC coil operating device can be energized by a low level DC signal from a computer or PLC and includes built-in transient suppression and LED "On" indicator.
Technical Specifications
Parameters and characteristics for this part
| Specification | LC2K1210F7 |
|---|---|
| Coil Voltage | 110 V |
| Contact Form | A, PST-NO, Form, 3 |
| Contact Rating (Current) | 12 A |
| Features | Auxiliary Contacts |
| Mounting Type | Chassis Mount, DIN Rail |
| Must Operate Voltage | 88 V |
| Must Release Voltage | 22 VDC |
| Operate Time | 20 ms |
| Operating Temperature (Max) | 50 °C |
| Operating Temperature (Min) | -25 °C |
| Pin Count | 3 pins |
| Release Time | 20 ms |
| Switching Voltage AC (Max) | 690 VAC |
| Termination Style | Screw Terminal |
