DQD6N-24-S40-DIN
ActiveBel Fuse Inc.
DC-DC, ISOLATED, 6 W, 9~36 VDC I
DQD6N-24-S40-DIN
ActiveBel Fuse Inc.
DC-DC, ISOLATED, 6 W, 9~36 VDC I
Description
General part information
DQD6N-24-S40-DIN
DC-DC, ISOLATED, 6 W, 9~36 VDC I
Technical Specifications
Parameters and characteristics for this part
| Specification | DQD6N-24-S40-DIN |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | CE, UKCA |
| Current - Output (Max) | 150 mA |
| DC Voltage - Input (Max) | 36 V |
| DC Voltage - Input (Min) | 9 V |
| Efficiency | 86 % |
| Input Type | DC |
| Number of Outputs | 1 |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Power (Watts) | 6 W |
| Standard Number | 62368-1 |
| Voltage - Isolation | 1500 Vrns |
| Voltage - Output 1 | 40 V |
