ZB4BW7A1721
ActiveSWITCH ACTUATOR, XB4 SERIES ILLUMINATED DOUBLE-HEADED PUSHBUTTON SWITCHES
ZB4BW7A1721
ActiveSWITCH ACTUATOR, XB4 SERIES ILLUMINATED DOUBLE-HEADED PUSHBUTTON SWITCHES
Description
General part information
ZB4BW7A1721
The ZB4BW7A1721 is a Ø22mm rectangular illuminated double-headed Pushbutton Switch Head for harmony XB4 series switches. This head has chromium plated metal bezel with integral LED, 2 flush push-buttons with black 'I' on white flush and white 'O' on black flush spring return operator and one central pilot light.
Technical Specifications
Parameters and characteristics for this part
| Specification | ZB4BW7A1721 |
|---|---|
| Actuator Type | Pushbutton, Rectangular (Dual) |
| Compatible Series | Harmony XB5, Schneider |
| Illumination | Illuminated |
| Panel Cutout Dimension | 22 mm |
| Panel Cutout Shape | Round |
| Requires | Illumination Source, Contact Block(s) |
| Type | Momentary |
